Description
Features:
1.Available 25ton load capacity
2.Available solid body or plate-type style
3.Available in a size range of 5/8” ~ 1-1/2”
4.Strictly tested according to API
5.Made from high-quality heat-treated alloy
Model |
Applicable for Diameter of Tubular(inch) |
Rated Capacity(Ton) |
SRE20 |
1/2, 5/8, 3/4, 7/8, 1, 1-1/8, 1-1/4, 1-1/2, |
20 |
SRE25 |
5/8, 3/4, 7/8, 1 |
25 |
Drawing:
Sucker Rod Elevator parts list
No. |
Name |
Quantity |
No. |
Name |
Quantity |
No. |
Name |
Quantity |
1 |
Body |
1 |
3 |
Button latch |
4 |
5 |
Rear Latch |
2 |
2 |
Bail |
1 |
4 |
Front Latch |
2 |
6 |
Spring |
2 |
